XYZ axis travel

450/260/400

Spindle nose to table   (mm)

120-520

Table size   (mm)

700*240

Max.Table  load  (Kg)

200KG

T-slot

3-14

Spindle Taper

BT40

Spindle speed    ( r.p.m)

8000

Main motor  ( Kw)

3.7

Rapid feed (X/Y/Z)   (m/min)

15/15/15( Linear )

Cutting speed     mm/min

1-5000

Positioning accuracy   (mm)

0.01( Linear )

Repeatability accuracy    (mm)

0.007( Linear )

Tool changer  Type

Funnel Type Tool Charger

Tool changer Number

12 T

Linear Guideway Width  ( HIWIN Linear)

 25mm

Screw Diameter

 2506

Screw Level

C3

Bearing of Screw

2047

Screw Bearing Level

P3

Power supply

3 Phase380V50Hz

Machine weight  ( KG)

1700/1850

Machine Size  (L/W/H )

2400*2200*2500mm
