M7150Hydraulic Surface Grinder
Item Number： HP-SG-017
Machine Condition： NEW
Machine in stock： 1
Delivery time： 60 Days
Payment terms： T/T
Warranty： 1 Year
Afer Sales Service：
Product introduction
M7150Hydraulic Surface Grinder
Main Feature
★The machines` casting bodys are made of special alloy steel through strict
processing and heat treatment technology. High precision and good rigidity.
★The table ball track is made of steel material, high-density steel balls, wear-
resistant, light moving, and high efficiency. The manual worktable is driven by a
synchronous belt with high stability.
★The front and rear double V-shaped slides, and precision shoveling, not only
slide smoothly and wear-resistant.
★The high-precision sleeve type grinding head adopts ultra-precision beveled
rolling bearings.Such a design ensures long life of the bearing and the surface
accuracy of the grinding.
Model | unit | M7150 |
PLC | Siemens PLC Board | |
Control Panel | 325mm | |
Table Size (L×W) | mm | 1250*500 |
Max Longitudinal movement of work table | mm | 1350 |
T-Slot number×width | 5×18 | |
Speed of work table(stepless) | m/min | 3-25 |
Max distance from spindle center to table surface | mm | 800 |
Max movement of grinding wheel Cross movement(Manual and Hydraulic) | mm | 580 |
Max movement of grinding wheel Vertical movement(Manual) | mm | 600 |
Spindle speed | rpm | 1440 |
Wheel Size(Outer diameter×width×Inner diameter) | mm | φ400x40xφ127 |
Scale on the vertical handwheel | mm | 0.01 |
Vertical movement of wheel head of per handwheel | mm | 1.00 |
Total power of motor | km | 16 |
Grinding wheel motor Power | w | 7.5 |
Grinding wheel motor Speed | r/min | 1440 |
Up-Down Servo Motor Power | kw | 2.3 |
Front-Back Servo Motor Power | kw | 1.5 |
Oil pump motor Power | w | 4 |
Oil pump motor Speed | r/min | 960 |
Coolant pump motor Power | w | 0.125 |
Coolant pump motor Speed | r/min | 2800 |
Oil pump Flow | L/min | 125 |
Oil pump Working pressure | Mpa | 1.5 |
The parallelism of working surface to base level | mm | 1000:0.015 |
Surface roughness | μm | Ra0.63 |
Weight | kg | 5300/6000 |
Overall dimension(L×W×H) | mm | 3210×1750×2350 |
1250x500mm Electrical Magnetic Table
400*40*127mm Grinder Wheel With 9Kw Motor
Siemens Smart Line PLC Touch Screen Panel
+English,Russian Language can be choosen
Siemens PLC Control Device
Hydrualic Station for Left/Right Feed (X Axis)
Y Axis and Z Axis Servo Motor
Q1. How can l get a quotation?
A. Leave us massage with your purchase requements and we will reply
you ASAP. And you may contact us directly by Trade Manager or Telephone.
Q2. Can you provide customized machine or SPM (Special purposemachine)?
A. Yes, we provide smart CNC solutions for our customer, in order increase efficiency.
Q3. Can you provide training for operation CNC machines?
A. Yes, free training in our factory is available.
Q4. How about your price?
A. Send me details about what you need, you will get the best
price in China. The price is competitive over the world.
Q5.What's the delivery time, and what's the package?
A. Normally the delivery time is about 30-45 days. All our CNC machines
packed with sea worthy package.
