Working table

Table Size (L×W)

mm

480*200

Max movement of working

table(L×W)

mm

530*220

T-Slot(number×width)

mm

1x14

Grinding wheel

Max distance from spindle center to table surface

mm

450

Wheel Size

(Outer diameter×width×Inner diameter)

mm

Ф200x20xФ31.75

Wheel speed

50HZ

r/min

2850

60HZ

3440

Feed amount

Longitudinal speed of working table

m/min

3-20

Cross feed(front and rear) on handwheel

Per revolution

mm

5.0

Per graduation

mm

0.02

Vertical

(up and down) feed

on handwheel

Per revolution

mm

1.25

Per graduation

mm

0.01

Motor power

Spindle motor

kw

1.1

Coolant pump motor

w

40

Hydraulic system

Hydraulic motor

Kw

1.5

Working pressure

Mpa

3

Oil tank capacity

L

80

Max flow

L/min

18

Working precision

The parallelism of working surface to base level

mm

300:0.005

Surface roughness

μm

Ra0.32

 Weight

Net

Kg

850

Gross

kg

950

Overall dimension(L×W×H)

mm

1680*1140*1760

Package dimension(L×W×H)

mm

1630*1170*1940
