Working table

Table Size (L× W)

mm

460×180

Max movement of working table(L× W)

mm

500×190

T -Slot number×width

mm

1×14

Grinding head

Max distance from spindle center to table surface

mm

335

Wheel Size（Outer diameter×width×Inner diameter）

mm

φ180×13×Φ31.75

Wheel speed

50HZ

r/min

2850

60HZ

3440

Feed amount

Vertical feed on  handwheel

Per revolution

mm

1.25

Per graduation

mm

0.01

Cross feed on handwheel

Per revolution

mm

5

Per graduation

mm

0.02

Motor power

Spindle motor

kw

1.1

Coolant pump motor

w

40

Working precision

The parallelism of working surface to base level

mm

300:0.005

Surface roughness

μm

Ra0.32

Weight

Net

kg

650

Gross

kg

750

Overall dimension（L×W×H）

mm

1550x1150x1590

Package dimension（L×W×H)

mm

1000x1150x1760
